| Resilient seated gate valves | |||||
| STANDARD MATERIALS OF MAIN PARTS | |||||
| ITEM | PART NAME | MATERIAL | 7 | Sealing Ring | Brass |
| 1 | Body | Ductile Iron | 8 | Gland | Ductile Iron |
| 2 | Disc | Ductile Iron+NBR/EPDM | 9 | Handwheel | Ductile Iron |
| 3 | Bonnet | Ductile Iron | 10 | Bonnet Gasket | NBR/EPDM |
| 4 | Stem | Stainless Steel 410,431,316 | 11 | O Ring | NBR |
| 5 | Stem Nut | Brass | 12 | Dust Ring | NBR |
| 6 | Holding Ring | Brass | 13 | Bonnet Bolts | Stainless Steel |
Please contact us for additional information.
